Fineness:325 Mesh
Input size: 20-35mm
Output size; 80-600 mesh
Production: 1-15T/H
Materials: limestone, calcite, dolomite, barite, talc, calcium carbonate, gypsum, bentonite, kaolin, petroleum coke, coal etc.
Firstly, read the instruction carefully.Due to the dust in the working environment, the working conditions of raymond mill equipment are bad.In order to ensure the normal operation and service life of ramond mill, please lubricate according to the lubrication table.
Secondly,do the first oil exchange in one week.The main mill drive, analysis engine bearing, elevator worm gear box and blower are lubricated with lubricating oil.When the new raymond mill is in use, the rotating part and the gears will run together. There will be a certain amount of iron filings, particles fall.There will be a certain amount of iron filings, particles fall.In order not to make the machine too fast wear, please change oil in a week after the boot oil.Users can change the oil according to the deadline of the lubrication table.
Thirdly,pay attention to the oil level and to clear the raymond mill. Please clean the interior with kerosene or diesel oil after draining the old oil.After washing, drain the oil and fill it with oil.Also pay attention to the oil level.Main mill drive box with oil mark line as oil level.The oil level of analysis machine bearing housing and elevator worm gear box should not be higher than half of the oil mark.The oil level of the blower should be between the two lines of the oil needle.If there is too little oil, the Raymond mill will not be lubricated properly.If too much will increase the power consumption, the raymond mill is prone to overheating, and may leak oil.There is a screw pump inside the main engine.This screw pump specializes in providing lubricating oil for the main engine transmission bearings.
Fourthly,please make sure the rotation’s direction of the screw pump is right.If the direction is reversed, the oil pump will not work, resulting in no oil bearing lubrication..Filter the oil before adding lubricating oil.
Users should clean the Grease nozzles to avoid bringing mud and sand into the oil.The working conditions of the raymond mill roll assembly are particularly harsh. The bearings should be lubricated and cleaned regularly.
